Description
Description
Use
This range of accessories is used to branch permanently 12/20 (24) kV MV cables, whether they are of synthetic insulation or impregnated paper.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Conductor material
Copper or Aluminum
Technology
Cold shrink
Dimensional characteristics
Dimensional characteristics
Conductor section of the branched cable, range
50 ... 240 mm²
Conductor section of the main cable, range
95 ... 240 mm²
Electrical characteristics
Electrical characteristics
Rated Voltage Uo/U (Um)
-
Dielectric withstand voltage, 50Hz 1mn
55 kV
Impulse voltage
125 kV
Maximal partial discharge at 2Uo
10 pC
Usage characteristics
Usage characteristics
Ambient installation temperature, range
5 ... 40 °C
